Specifications | |
Material | BK7 |
Dimension Tolerance | +0.0/-0.2mm |
Thickness Tolerance | ±0.2mm |
Clear Aperture | >90% |
Flatness | λ/[email protected] per 25mm range |
Surface Quality | 60/40 scratch and dig |
Coating | Dielectric HR coating on one surface, R>99.5% for random polarization, rear surface ground or inspection polished |
Damage Threshold | >5J/cm2, 20ns, 20Hz, @1064nm |
