Specifications
Material : BK7
Dimension Tolerance : +0.0/-0.2mm
Thickness Tolerance : ±0.2mm
Clear Aperture : >90%
Parallelism : <1 arc-min seconds
Surface Quality : 60/40
Flatness : <λ/4@633nm per 25mm
Coating(AOI=45deg) : S1: Partial reflectance coating
  S2: AR coating
Damage Threshold : >1J/cm2, 20ns, 20Hz, @1064nm


Click to Enlarge



规格/叙述 交货日期 单价 数量 购物车
P-V3MUBA5504-1R

Circular/Ø25.4*3.0mm/400-700nm/50:50(R/T)

3 weeks
RMB¥ 询价
P-V3MUBA5504-2R

Circular/Ø50.8*3.0mm/400-700nm/50:50(R/T)

3 weeks
RMB¥询价
P-V3MUBA5504-1S

Square/25.4*25.4*3.0mm/400-700nm/50:50(R/T)

3 weeks
RMB¥询价
P-V3MUBA5504-2S

Square/50.8*50.8*3mm/400-700nm/50:50(R/T)

3 weeks
RMB¥询价
P-V3MUBA7304-1R

Circular/Ø25.4*3mm/400-700nm/70:30(R/T)

3 weeks
RMB¥询价
P-V3MUBA7304-2R

Circular/Ø50.8*3.0mm/400-700nm/70:30(R/T)

3 weeks
RMB¥询价
P-V3MUBA3704-1R

Circular/Ø25.4*3.0mm/400-700nm/30:70(R/T)

3 weeks
RMB¥询价
P-V3MUBA3704-2R

Circular/Ø50.8*3.0mm/400-700nm/30:70(R/T)

3 weeks
RMB¥询价
